Math2mat
|
Public Member Functions | |
| BinaryOut (OutputStream os) | |
| BinaryOut () | |
| BinaryOut (String s) | |
| BinaryOut (Socket socket) | |
| void | flush () |
| void | close () |
| void | write (boolean x) |
| void | write (byte x) |
| void | write (int x) |
| void | write (int x, int r) |
| void | write (double x) |
| void | write (long x) |
| void | write (float x) |
| void | write (short x) |
| void | write (char x) |
| void | write (char x, int r) |
| void | write (String s) |
| void | write (String s, int r) |
Binary output. This class provides methods for converting primtive type variables (boolean, byte, char, int, long, float, and double) to sequences of bits and writing them to an output stream. The output stream can be standard output, a file, an OutputStream or a Socket. Uses big-endian (most-significant byte first).
The client must flush() the output stream when finished writing bits.
The client should not intermixing calls to BinaryOut with calls to Out; otherwise unexpected behavior will result.
Definition at line 37 of file BinaryOut.java.
| m2m.backend.verifpga.BinaryOut.BinaryOut | ( | OutputStream | os | ) |
Create a binary output stream from an OutputStream.
Definition at line 47 of file BinaryOut.java.
| m2m.backend.verifpga.BinaryOut.BinaryOut | ( | ) |
Create a binary output stream from standard output.
Definition at line 54 of file BinaryOut.java.
| m2m.backend.verifpga.BinaryOut.BinaryOut | ( | String | s | ) |
Create a binary output stream from a filename.
Definition at line 61 of file BinaryOut.java.
| m2m.backend.verifpga.BinaryOut.BinaryOut | ( | Socket | socket | ) |
Create a binary output stream from a Socket.
Definition at line 72 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.close | ( | ) |
Close and flush the binary output stream. Once it is closed, you can no longer write bits.
Definition at line 137 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.flush | ( | ) |
Flush the binary output stream, padding 0s if number of bits written so far is not a multiple of 8.
Definition at line 128 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | String | s | ) |
Write the string of 8-bit characters to the binary output stream.
| s | the String to write. |
| RuntimeException | if any character in the string is not between 0 and 255. |
Definition at line 262 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | char | x, |
| int | r | ||
| ) |
Write the r-bit char to the binary output stream.
| x | the char to write. |
| r | the number of relevant bits in the char. |
| RuntimeException | if r is not between 1 and 16. |
| RuntimeException | if x is not between 0 and 2r - 1. |
Definition at line 246 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | char | x | ) |
Write the 8-bit char to the binary output stream.
| x | the char to write. |
| RuntimeException | if x is not betwen 0 and 255. |
Definition at line 234 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | short | x | ) |
Write the 16-bit int to the binary output stream.
| x | the short to write. |
Definition at line 224 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | float | x | ) |
Write the 32-bit float to the binary output stream.
| x | the float to write. |
Definition at line 216 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | long | x | ) |
Write the 64-bit long to the binary output stream.
| x | the long to write. |
Definition at line 201 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | double | x | ) |
Write the 64-bit double to the binary output stream.
| x | the double to write. |
Definition at line 193 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | int | x, |
| int | r | ||
| ) |
Write the r-bit int to the binary output stream.
| x | the int to write. |
| r | the number of relevant bits in the char. |
| RuntimeException | if r is not between 1 and 32. |
| RuntimeException | if x is not between 0 and 2r - 1. |
Definition at line 178 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | int | x | ) |
Write the 32-bit int to the binary output stream.
| x | the int to write. |
Definition at line 164 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | byte | x | ) |
Write the 8-bit byte to the binary output stream.
| x | the byte to write. |
Definition at line 156 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | boolean | x | ) |
Write the specified bit to the binary output stream.
| x | the boolean to write. |
Definition at line 148 of file BinaryOut.java.
| void m2m.backend.verifpga.BinaryOut.write | ( | String | s, |
| int | r | ||
| ) |
Write the String of r-bit characters to the binary output stream.
| s | the String to write. |
| r | the number of relevants bits in each character. |
| RuntimeException | if r is not between 1 and 16. |
| RuntimeException | if any character in the string is not between 0 and 2r - 1. |
Definition at line 276 of file BinaryOut.java.
